A 2014 Skoda Octavia III came in with nothing but an illuminated engine warning light and a single P2002 fault code stored. The technician had noted 'lyser motor lampa' on the job card, leaving us with a very broad complaint and a highly specific code. Dealing with particulate filter efficiency codes on the 1.6 TDI usually means a choice between firing the parts cannon or digging deep into live data. The diagnostic platform we build analyzed this code against the 1.6 TDI CRKB engine with the Delphi DCM 6.2 management system, giving us a clear hierarchy of probabilities to work through.
The Drive Cycle Disconnect
The most likely cause, ranked at an 85 percent probability with a medium severity, was soot accumulation and incomplete regeneration caused by short trips. The Delphi DCM 6.2 system is extremely strict about when it allows an automatic regeneration of the diesel particulate filter. The engine must reach a full operating temperature of at least 80 degrees Celsius. Once there, the vehicle needs to be driven under a steady load for 15 to 25 minutes to push the exhaust temperature before the DPF up to between 550 and 650 degrees Celsius.
When a car lives its life in stop-and-go city traffic, these regeneration cycles are either repeatedly interrupted or never initiate at all. The filter saturates with soot, and the engine control unit sees that the calculated soot mass has deviated from the expected pressure drop curve. This is exactly what triggers the P2002 code. The recommended testing path here starts at the diagnostic tool. We look at the live data for Soot Mass Measured versus Soot Mass Calculated. Next, we check the drive cycle history to see the distance and time since the last successful regeneration. If the numbers confirm a blocked filter without hardware damage, a forced service regeneration is the immediate next step.
Trusting the Sensor Data
If the soot mass numbers look acceptable, the next suspect is the G450 differential pressure sensor, ranked at a 75 percent probability. This piezoresistive sensor measures the pressure difference between the DPF inlet and outlet. On these VAG vehicles, the sensor is notorious for internal membrane fatigue, moisture ingress, and calibration drift. The engine control unit expects a very precise value. If the sensor develops an offset of just a few millibar, the ECU detects a discrepancy between the calculated exhaust resistance and the measured value, setting the P2002 code even if the particulate filter is perfectly healthy.
Testing this requires verifying the zero-point calibration with the ignition on and the engine off. We also need to measure the 5-volt supply, the signal voltage, and the ground directly at the sensor connector. The definitive test is to hook up a manual hand pump and a physical pressure gauge to the sensor, then compare the analog gauge reading against the live data value on the scanner.
Thermal Stress on the Plumbing
Ranked closely behind the sensor at 70 percent is the condition of the pressure hoses leading to it. The rubber hoses and stainless steel pipes that carry exhaust pressure from the DPF up to the G450 sensor sit in a brutally hot environment behind the engine block. The rubber bakes, dries out, and cracks. Sometimes it melts entirely against a heat shield, and occasionally rodents chew through it. We also see the metal pipes choke up completely with baked condensation and soot.
A pneumatic leak on the high-pressure side means the sensor registers a lower pressure drop than what actually exists in the exhaust stream. The control unit interprets this as a particulate filter that has lost its filtration capacity or is leaking straight through. The diagnostic procedure involves a visual and tactile inspection of the rubber lines and clamps. Following that, we run a smoke test or pressurize the lines to find microscopic cracks, and blow compressed air through the metal pipes to ensure they are clear.
The Catastrophic Failure
The final scenario in our diagnostic ranking, sitting at 60 percent but carrying a high severity flag, is a cracked or internally damaged ceramic monolith. The filter core in these engines is made of silicon carbide or cordierite. It is highly susceptible to thermal shock and uneven temperature gradients, which happen frequently during interrupted regeneration cycles. When the monolith cracks, it creates microscopic or even highly visible channels that allow unfiltered exhaust gas to slip straight through.
This bypass lowers the exhaust backpressure relative to the airflow. The engine control unit catches this anomaly and logs P2002. There is a very fast way to confirm this without pulling the exhaust apart: the tailpipe wipe test. If you wipe the inside of the tailpipe with a white paper towel or rag and it comes out sooty, the filter is breached. A healthy DPF will always leave a clean tailpipe. If the wipe test fails, an endoscope inspection through the temperature sensor port will usually reveal the shattered ceramic.
When a P2002 code shows up in your bay, do you start by checking the tailpipe for soot, or do you head straight for the livedata on the scanner?
